Multi Core PVC Insulated Electrical Cable 4x2.5mm² 0.6/1kV Rated Voltage Flame Retardant

Product Categories

Minfeng Cable Group Co., Ltd

Trust Seal

Verified Supplier

Credit Check

Supplier Assessment

Contact Now

Cores No : 1-5

Outer Sheath Color : Black or as per required

Insulation : XLPE

Halogen Free : Available

Core Mark : Number or Color Strip

Type : YJV YJV22 YJV32

Flame Retardant : Available

Conductor Material : copper or Al-alloy

Contact Now

Multi Core PVC Insulated Kabel NYA NYM 4x2.5 Electrical Cable

Multi Core PVC Insulated Kabel NYA NYM 4x2.5 Electrical Cable Suppliers in UAE

Product Name	Copper core or aluminum core XLPE insulated PVC sheathed power cable Copper core or aluminum core XLPE insulated steel tape armoured PVC sheathed power cable Copper core or aluminum core XLPE insulated steel wire armoured PVC sheathed power cable
Rated Voltage	0.6/1kV, 1.8/3kV, 3.6/6kV, 6/10kV, 8.7/15kV, 12/20kV, 21/35kV, 26/35kV
Standard	B/T12706-2008, GB/T12703-200, IEC60502-1-1997
Model	YJV, YJLV, YJV22, YJLV22, YJV32, YJLV32, YJV42, YJLV42
Armoured	Steel tape armored, steel wire armored Double galvanized steel tape or galvanized steel wire for three core power cable Double aluminium tape or aluminium wire for single power cable
Number of Cores	Single core, 2 cores, 3 cores, 4 cores, 5 cores, 3+1 cores, 3+2 cores, 4+1 cores, etc.
Common Size	1mm², 1.5mm², 2.5mm², 4mm², 6mm², 10mm², 16mm², 25mm², 35mm², 50mm², 70mm², 95mm², 120mm², 150mm², 185mm², 240mm², 300mm², 400mm², 500mm², 630mm², 800mm², 1000mm², etc.
Types	Ordinary type, flame-retardant type, fire-resistant type, low-smoke halogen-free type
Application	Power distribution engineering, power transmission engineering, electromechanical and hydropower installation engineering, power transmission, power supply installation system, control system, etc.

Installation Precautions

The minimum bending radius when laying the cable is not less than 10 times the outer diameter of the cable.
YJV / YJLV cables are laid indoors, in channels and pipes, and can also be buried in loose soil, which cannot bear external forces.
The YJV22 / YJLV22 cables are laid underground and can withstand external mechanical forces, but cannot withstand large tensile forces.
Special tools should be used for cable laying, such as pay-off racks, guide rollers, etc., to prevent mechanical damage during the laying process and keep away from heat sources.
When laying the cable through the pipe, the inner diameter of the pipe should not be less than 1.5 times the outer diameter of the cable. It is forbidden to squeeze the cable when passing through the pipe. The total area of the cable should not exceed 40% of the total area of the pipe.
